Description
Machine produced in Germany!

- Modular machine construction
- Ultrasonic sealing system with electronic self-calibration
- High-end Standard 6 sealing unit
- Easy accessibility and tool-free disassembly of strap way components
- Wear-free DC drives with integrated electronics
- Stepless turnable OP for many-sided operation
- Adjustable strap tension via potentiometer
- Programmable strap tension value
- Switching from maximum to material-friendly eco speed in the control
- Cycle counter integrated in the control
- Quick strap coil change
- Strap coil changeable from the front and the side
- Automatic strap threading system
- Strap end detection with ejection of remaining strap
- Automatic strap loop ejection
- Low energy consumption
- Stand-by mode
- 4 castors, 2 of them lockable
- CE marking inclusive declaration of conformity
- Structural coating RAL 5010, gentian blue
- Strapping release via foot pedal or OP
- Soft strapping selectable for sensitive packages
- Visualization of the functional status via color-coded display in the OP

Variants & Options
- Hold-down device
- Table extension
- Balls or rollers in the table plate
- Automatic adjustment of the strap tension by package height detection
- Lowering chassis H = 730 – 835mm to the front and rear, or outwards
- Manual strapping release via additional fixed or flexible foot pedal
- Automatic strapping release via ball switch or light sensor
- Early strap ending indication with signal in the OP
- Parameter control point for setting strapping parameters
- 4 swivel castors
- Signal light
- Hinged cable conduit
- Signal exchange via 16 pol contact socket
- Special painture according RAL scale

Technical details

Capacity: up to 58 cycles / min. at 5 mm strap width

Straps: 5, 6, 8, 9, 10 or 12 mm

Strap coil dispenser:
Core diameter: 200 mm
Core width: 190 mm
max. outer diameter: 430 mm

Electricity:
Voltage: 230 V, 50/60 Hz, 1 Ph
Power consumption: ca. 0.3 kW

Sealing unit: Standard 6 unit

Weight: 190 kg (at frame size 600 x 600)

Frame sizes:
500 x 400 mm
600 x 600 mm
800 x 400 mm
800 x 600 mm
1000 x 800 mm
1250 x 600 mm
1250 x 1000 mm
1650 x 600 mm
