Description

This strapping system consists of:
SoniXs TR-6 Base and
SoniXs TRI-6 Base

- Cross strapping without bundle turning
- Ultrasonic sealing system with electronic self-calibration
- Can be integrated into most production lines
- High-end Standard 6 sealing unit
- Easy accessibility and tool-free disassembly of strap way components
- Bundle positioning via increments by metrical input of the strapping positions
- Easy operation over digital display in the control panel
- TR-6 BASE: Selector switch for single, double or multiple strappings
- TRI-6 BASE: Cost-efficient, pneumatical hold-down device
- Potential-free contacts to up-stream and down-stream systems
- Open design without protective coverings - CE marking inclusive conformity declaration
- Extremely low energy consumption

Variants & Options
- Automatic adjustment of the strap tension by package height detection
- Options TR-Base:
- Cost-efficient, pneumatical backstop
- Cost-efficient, pneumatical hold-down device
- Table extension up to 60, 110 or 220 mm

Technical details

Capacity:
Up to 30 packages per minute

Straps:
Standard machine grade 5 or 9 mm wide PP straps

Strap coil dispenser:
Core diameter: 200 mm
Core width: 190 mm

Electricity:
Network data: 100 - 240 V, 50/60 Hz, 1 PH*
Power consumption: 0.60 kW

Weight: 805 kg (incl. hold-down device and backstop)

*Country-specific adaption possible
